Wonder Snail 120

120mm Cooling Fan

WS-120 is a static pressure optimized fan, with a focus channel design, the fan delivers focus and straight airflow that yields superior performance particularly in the use of heatsink and water-cooling radiator. Using Sealed Precision FDB, the fan is quiet, stable, and reliable for all kinds of usages in PC builds. Thanks to the newly designed frame and blade, WS-120 has exceptional cooling performance with the lowest noise level making it a great choice for the most demanding environments.

摘要大廈

Wonder Snail 120


Optimized for pressure demanding applications, WS-120 features a newly developed frame and blade that deliver straight and focus airflow, thus WS-120 is ideal for heatsink and radiator.


Focused Channel Design

Sealed Precision FDB

Featuring Sealed Precision FDB, WS-120 provides quiet operation as well as a long lifespan. The bearing and pressure shaft are made of high-quality compressed metal to guarantee minimum tolerance and excellent stability and reliability.


Silent Operation

Thanks to the newly developed fan design, WS-120 is optimized to achieve the best balance of performance and noise level. Equipped anti-vibration pad minimizes possible vibration transmission keeping applications at the lowest sound profile.

DSC05254
DSC05255
DSC05253
DSC05271
DSC05267
DSC05269
DSC05256
DSC05262
DSC05261
DSC05257
DSC05258
DSC05260

SPECIFICATIONS

Dimensions : 120 x 120 x 26mm

Bearing : Sealed Precision FDB


Life Span : 120,000 hrs


Voltage : 12V



Connector: 4-pin


Weight : 160 ± 10%


Accessories : screws X 4、tool-less screws X 4、
200 mm extension cable X 1

Model Number



WS1225FD12-P



WS1225FD18-P



WS1225FD24-P

Fan Speed

(RPM)



350±200~1200±10%



350±200~1800±10%

300±200~2400±10%

Air Flow

(CFM)



8.01~37.73



8.01~51.68

7.68~77.23

Static Pressure

(mmH2O / Pa)



0.07~0.89 / 0.69~8.70



0.07~1.74 / 0.69~17.06

​0.05~3.59 / 0.49~35.25

Noise

(dBA)



4.0~18.6



4.0~22.9

​3.0~29.3

Current

(A)



0.06



0.10



0.15
